TYM-IRONCRAFT 5′ LAND LEVELER STD DUTY
TYM-IRONCRAFT 5′ DUAL CUTTING EDGE GRADER BLADE
| Product Family | 3600 Series |
| Product | 3605 |
| Description | 5′ Standard Duty Dual Edge Grader |
| HP Required | 25 – 55 |
| Working Width | 60″ |
| Height | 33-3/4″ |
| Overall Width | 65-5/8″ |
| Overall Length | 52-7/8″ |
| # of Shanks | 4 |
| Scarifier Shank Construction | 3 Position Heat Treated shank with dimpled on hardened tips |
| Shank Adjustment | At grade level, 1-1/2″ and 3″ below grade level |
| A-frame Material | 3/8″ |
| Weight (lbs) | 490 lbs |
| Side Panel Thickness | 3/16″ |
| Side Panel Height | 15-11/16″ |
| Side Panel Length | 46-3/8″ |
| Scarifier Support Tube Construction | 4″ x 4″ x 1/4″ |
| Rear Beam Construction | 3″ x 3″ x 3/16″ |
| Skid Shoes | Replaceable 3/16″ x 2-3/4″ x 47-3/8″ |
| Hitch Type | Clevis Type |
| Hitch | Cat 1 |
- Category: Landscaping
- Model Number: 3605-TYM
- Condition: New
Equipment Gallery
More Equipment Info
Chassis
- Tires or Tracks: Tires
